6-5 POWER UNIT
Remove four bolts and electric part holder.
Remove IAC valve silencer.
Disconnect clutch rod from shift rod by loosening lock nut and
turnbuckle.
Remove throttle control lever
1 and clutch control lever 2.
Remove bolt and neutral switch
3 with bracket.
Remove two bolts 1 securing front panel bracket 2.
Remove screw
3 and clutch lever shaft 4.
Remove clutch rod arm
5 from crankcase .
Remove pin
6 and side cover seal 7.
Remove oil level dipstick
8.
