POWER UNIT 6-42
Remove two compression rings (top and 2 nd) and oil ring from
piston.
Mark cylinder number on conrod using quick dry paint.
Remove piston pin circlips as shown.
1
1. Piston pin circlip
Remove piston pin from conrod.
NOTE:
Reassemble each piston, piston pin and conrod in their original
combination and position.
