POWER UNIT 6-23
10. Apply engine oil lightly to housing bolts.
11. Lightly seat all housing bolts at first.
According to numerical order in figure, tighten bolts to 1/3
of specified torque, then 2/3 of specified torque and finally
to full specified torque.
" Camshaft housing bolt : 11 N
.
m (1.1 kg-m, 8.0 lb.-ft.)
12. Install gasket 1 and oil relief valve 2, then tighten valve
securely.
" Oil relief valve : 27 N
.
m (2.7 kg-m, 19.5 lb.-ft.)
13. Install timing chain. (See page 6-17)
14. Install oil pump assembly. (See page 6-13)
15. Adjust tappet clearance. (See page 2-9)
