DF140 “K2” (’02) MODEL 11-47
Remove the impeller 3, impeller key 6, pump under plate 4
and dowel pins 5.
Keep the impeller key 6 for reuse and discard the plate gas-
ket.
Remove three (
3
) bolts 1 and shift rod guide housing assem-
bly 2.
Remove the two (
2
) bolts 1 securing the propeller shaft bear-
ing housing to the gearcase.
Using special tools, draw out the propeller shaft bearing hous-
ing.
Remove the propeller shaft and bearing housing assembly.
\ 09930-30104: A Sliding hammer
09930-30161: B Propeller shaft remover
Hold the pinion nut securely, then fit special tool to the driveshaft
and loosen the pinion nut.
\ 09921-29410: Driveshaft holder
\
A
B
