DF140 “K2” (’02) MODEL 11-73
GEAR
• Inspect forward, reverse and pinion gear teeth and engaging
dogs.
Replace gears if damaged or worn.
• Inspect forward gear thrust bearing. Replace bearing if pit-
ted, noisy or rough.
PROPELLER SHAFT COMPONENTS
• Inspect horizontal slider and connector pin.
Replace if wear, damage or other abnormal condition.
• Inspect clutch dog shifter. Replace if chipped, worn or dam-
aged.
• Inspect dog pin. Replace if bent or worn.
• Inspect propeller shaft/splines. Replace if worn, twisted or
damaged.
• Inspect thrust bearing. Replace bearing if pitted, noisy or
rough.
PROPELLER SHAFT BEARING HOUSING
• Inspect housing. Replace if cracked or damaged.
• Inspect forward gear bearing. Replace bearing if pitted, noisy
or rough.
• Inspect bearing. Replace bearing if pitted, noisy or rough.
• Check condition of oil seal and O-ring.
Replace the seals if nicked, cut or worn.
