DF140 “K2” (’02) MODEL 11-75
DRIVESHAFT
Inspect driveshaft/splines. Replace if worn, twisted or damaged.
Inspect driveshaft bearing, replace if pitted, noisy or rough.
DRIVESHAFT OIL SEAL HOUSING
• Inspect housing. Replace if cracked or damaged.
• Check condition of oil seals. Replace if nicked, cut or worn.
• Inspect O-ring. Replace if worn, nicked or cut.
Replacing driveshaft oil seal
1. With the oil seal remover, draw the two oil seals out of the
driveshaft oil seal housing.
\ 09913-50121: Oil seal remover
2. Apply Water Resistant Grease to the inner circumference
of the driveshaft oil seal housing.
N 99000-25161: Water Resistant Grease
3. Grease the inner lips of the seal.
With the lips facing away from driveshaft bearing, place
seal in position and drive it into the oil seal housing.
Direction of
water pump case
