TRANSMISSION AND CRANKSHAFT 10-9
TRANSMISSION REASSEMBLY
NOTE:
* Seat the snap ring in the groove and locate its end as shown in
the illustration.
* Replace the removed snap ring with a new one.
• Apply transmission oil to the following parts: driveshaft, coun-
tershaft, transmission gears, bearings, gearshift forks, gear-
shift shafts, gearshift cam.
• Reassemble the driveshaft 1 and countershaft 2 with gears
installed.
Left Right
Thrust
Sharp edge
W
asher
Washer
