Suzuki RM85L - Engine Removal Procedure

5-2 ENGINE REMOVAL AND INSTALLATION
ENGINE REMOVAL AND INSTALLATION
REMOVAL
• Remove the frame covers 1 (left & right) and seat 2.
• Remove the clamps 3.
• Turn the fuel valve lever to the “OFF” position and disconnect
the fuel hose.
• Remove the radiator cover 4.
• Remove the fuel tank mounting bolts 5, left and right.
• Remove the fuel tank by unhooking the band 6 from the
hooked part.
• Drain transmission oil. (2-7)
• Drain engine coolant. (12-3)
• Remove the exhaust pipe fitting springs with the special tool.
 09920-20310: Spring hook
