CLUTCH 7-5
• Replace the gasket with a new one.
• Install the dowel pins.
• Align the clutch release rack teeth with the pinion gear.
• Align the water pump empeller to the crankshaft end.
• Install the clutch cover.
• Tighten the bolts diagonally.
• Reassemble the rear brake pedal. (15-14)
• Install the clutch release arm 1.
• Install the kick starter lever 2.
• Pour transmission oil. (2-7)
• Pour engine coolant. (2-8)
• Inspect the clutch cable play. (2-9)
CLUTCH SLEEVE HUB REMOVAL
• Remove the pressure plate and clutch plates. (7-3)
• Flatten the lock washer 1.
• Hold the clutch sleeve hub with the special tool and loosen
the nut.
09920-53740: Clutch sleeve hub holder
• Remove the clutch sleeve hub 2.
