17-4 REAR SUSPENSION
SPRING REMOVAL
• Remove the rear shock absorber unit from the frame.
(17-3)
• Loosen the lock-nut 1 and turn the adjuster 2 with the spe-
cial tool.
• Turn the lock-nut 1 and adjuster 2 fully to the end of the
thread.
 09910-60611: Universal clamp wrench
• Remove the spring seat 3, spring retainers 4 and the spring
5 from the rear shock absorber.
REAR SHOCK ABSORBER INSPECTION
• Inspect the rear shock absorber for oil leakage.
• Inspect the damper rod for scratch, damage and smooth
movement.
• Inspect the bump rubber for deterioration and damage.
• Inspect the damper rod hidden by the bump rubber by moving
the bump rubber.
• Inspect the upper bushing for damage.
