Suzuki RM85L - Kick Starter Removal Procedure

KICK STARTER 8-3
KICK STARTER
REMOVAL
• Drain transmission oil. (2-7)
• Drain engine coolant.
• Remove the kick starter lever.
• Remove the clutch assembly. (7-5)
• Remove the snap ring 1.
• Remove the kick idle gear 2.
• Remove the kick starter drive gear 3.
• Install the kick starter lever temporally to remove the kick
starter shaft.
• Turn the kick starter lever counterclockwise until the kick
starter 4 come off the kick starter guide 5.
• Remove the following parts from the kick starter shaft:
Spacer 6
Kick return spring 7
Washer 8
Kick starter 9
Spring 0
Kick starter shaft A
• Remove the kick starter guide B and kick starter stopper.
