Suzuki RM85L - Disc Plate and Rear Sprocket Replacement

FRONT AND REAR WHEELS 14-7
DISC PLATE REPLACEMENT
• Remove the front and rear wheels. (14-3 and -5)
• Replace the disc.
• Apply THREAD LOCK SUPER “1322” to the screws.
 99000-32110: THREAD LOCK SUPER “1322”
• Tighten the screws and nuts 1 (front only) to the specified
torque.
 Brake disc screw : 8.5 N·m (0.85 kgf-m, 6.0 lb-ft)
Front brake disc nut : 8.5 N·m (0.85 kgf-m, 6.0 lb-ft)
NOTE:
When installing the front disc, first tighten the screws to the
specified torque, and then tighten the nuts
1 to the specified
torque.
REAR SPROCKET REPLACEMENT
• Remove the rear wheel. (14-5)
• Replace the rear sprocket.
• Tighten the nuts to the specified torque.
 Rear sprocket nut: 40 N·m (4.0 kgf-m, 29.0 lb-ft)
