17-14 REAR SUSPENSION
• Remove the cushion rod 1 from the cushion lever 2.
REAR SUSPENSION LINKAGE INSPECTION
• Inspect the cushion lever and cushion rod for damage.
• Inspect the dust seals and spacers for damage.
• Inspect the bearings for damage.
• Insert the spacers into the bearings and inspect them for
smooth movement.
CUSHION LEVER AND CUSHION ROD
BEARING REPLACEMENT
• Remove the spacers and dust seals.
• Remove the circlips.
• Remove the bearings with the special tool.
09921-20220: Bearing remover set
