18-4 SERVICING INFORMATION
ELECTRICAL Unit: mm (in)
BRAKE + WHEEL Unit: mm (in)
ITEM SPECIFICATION NOTE
Spark plug Type NGK: BR10ES
Gap
0.7 – 0.8
(0.028 – 0.031)
Spark performance Over 8 (0.3) at 1 atm.
Ignition coil resistance Primary 0.2 – 1.0 Ω W/Bl – Ground
Secondary 12 – 20 kΩ
Plug cap – Ground
Magneto coil resistance 100 – 160 Ω B/R – R/W
140 – 230 Ω R/W – B/W
240 – 380 Ω B/R – B/W
Ignition coil primary peak voltage
200 V and more
+ : Ground
- : W/Bl
ITEM STANDARD LIMIT
Brake lever play 5 – 20
(0.20 – 0.79)
—
Brake disc thickness
Front
2.8 ± 3.2
(0.110 ± 0.126)
2.5
(0.10)
Rear
2.85 ± 3.15
(0.112 ± 0.124)
2.5
(0.10)
Brake disc runout
—
0.30
(0.012)
Master cylinder bore
Front
11.000 – 11.043
(0.4331 – 0.4348)
—
Rear
12.700 – 12.743
(0.5000 – 0.5017)
—
Master cylinder piston diam.
Front
10.957 – 10.984
(0.4314 – 0.4324)
—
Rear
12.657 – 12.684
(0.4983 – 0.4994)
—
Brake caliper cylinder bore
Front
30.230 – 30.306
(1.1902 – 1.1931)
—
Rear
27.000 – 27.076
(1.0630 – 1.0660)
—
Brake caliper piston diam.
Front
30.150 – 30.200
(1.1870 – 1.1890)
—
Rear
26.920 – 26.970
(1.0600 – 1.0618)
—
Wheel rim runout
Axial —
2.0
(0.08)
Radial —
2.0
(0.08)
Wheel axle runout
Front —
0.25
(0.010)
Rear —
0.25
(0.010)
Tire size
Front
70/100-17 40M RM85 —
70/100-19 42M RM85L —
Rear
90/100-14 49M RM85 —
90/100-16 52M RM85L —
