tracking
SYNRAD FH Series Flyer Operator’s Manual Version 3.4
121
Tracking denitions
Figure 5-4 Tracking Window
Target Area
The Target Area is the area on the part, or array of parts, that will be lased with the Mark as parts
move underneath the FH Flyer head. See Figure 5-5.
Usable
Field
Size
Mark Pitch
ABCD1234
ABCD1234
Part
Motion
0°
ABCD1234
Tracking Window
Figure 5-5 T
arget Area
Part
Motion
270°
ABCDEFG
1 2 3 4 5 6
Target Area
Part 2 of X
Part 1 of X
ABCDEFG
1 2 3 4 5 6
