SYNRAD FH Series Flyer Operator’s Manual Version 3.4
101
Tracking hardware
Figure 5-16 Wiring diagram for current-sinking (NPN open collector) part sensors using
Flyer’s built-in power supply
Figure 5-17 shows a customer-supplied power supply driving a current-sourcing PNP open collector
part sensor. Figure 5-18 shows how to power the same type part sensor from Flyer’s +15 VDC power
supply.
25
24
15
14
13
12
2
1
PA RT SENSOR
V+
OUT
GND
8
PIN # SIGNAL NAME
20
IN0_A
8
IN0_B
1
+ 15 V
14
+ 15 RTN
20
Figure 5-17
Wiring diagram for current-sourcing (PNP open collector) part sensors
25
24
15
14
13
12
2
1
DC POWER SUPPLYPA RT SENSOR
V+
GND
V+
GND
8
PIN # SIGNAL NAME
20
IN0_A
8
IN0_B
20
OUT
