SYNRAD FH Series Flyer Operator’s Manual Version 3.4
170
FH Flyer/Firestar t70i package
outline drawing
Figure 6-27
FH Flyer/Firestar t70i package outline and mounting dimensions
A
REV ECO
1429
DATE DESCRIPTION
ADDED NOTE 3, ITEM 14, RTP
DB
@
TOLERANCES UNLESS NOTED:
.x = ±0.1
.xx = ±0.02
.xxx = ±0.005
ANGLE = ±2.0°
MATERIAL:
. FINISH: . . .
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN PA RT WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
DESCRIPTION:
PA RT NUMBER: SHEET
1 OF 1
UNITS: INCHES SIZE:
B
DB: *** CATEGORY: FINISH CLASS:
. .
SEE TABLE
ASSY., RAIL, 48-5/100E/125E FH SERIES
DWG/FILE NUMBER: 230-18121-00 DRAWN BY: CHECKED BY: APPROVED BY:
DATE: DATE: DATE:
Pro/E
SYNRAD INC.
6500 Harbour Heights Pkwy Mukilteo, WA 98275 Phone: (425)349-3500 Fax: (425)485-4882
SEE BOM
PA RT NUMBER DESCRIPTION
230-19674-08 230-19674-10
48-5
100E
230-19674-12 125E
48-5 WILL USE THESE HOLES
100E WILL USE THESE HOLES
125E WILL USE THESE HOLES
HOLES ORIENTED CLOSER
TO THIS EDGE
MARKING HEAD
ORIENT BEVEL AS SHOWN
48-5 IS SHOWN 100/125E PICTURE WILL DIFFER
