SYNRAD FH Series Flyer Operator’s Manual Version 3.4
172
Figure 6-28
FH Flyer/Firestar t-Series package outline and mounting dimensions
FH Flyer/Firestar f100 package
MARKING HEAD
V40 FAN-COOLED
LASER SHOWN
REV
B
ECO
3575
DATE
10-OCT-07
REVISE NOTES
DESCRIPTION DB
T-SERIES AIR-COOLED WILL USE THESE HOLES
T-SERIES WATER-COOLED WILL USE THESE HOLES
V40 AIR-COOLED WILL USE THESE HOLES
V40 WATER-COOLED WILL USE THESE HOLES
F100 WILL USE THESE HOLES
ORIENT BEVEL
AS SHOWN
SYNRAD INC. 4600 Campus Place Mukilteo, WA 98275
Phone: (425)349-3500
Fax: (425)349-3667
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
TOLERANCES UNLESS NOTED:
.X = ±0.1
.XX = ±0.01
.XXX = ±0.005
MATERIAL:
SEE BOM
ANGLE = ±2.0°
FINISH:
DESCRIPTION
ASSEMBLY - RAIL, FIRESTAR, V40/T-SERIES/F100
PART NUMBER:
230-18747-02
SHEET 1 OF 1
UNITS: INCHES
SIZE: B
DB: pdmdb
CATEGORY:
FINISH CLASS:
DWG/FILE NUMBER: 230-18747-02
DRAWN BY:
CHECKED BY:
APPROVED BY:DATE:
DATE:
DATE:
29-Aug-02
