getting started
36
SYNRAD FH Series Flyer Operator’s Manual Version 3.4
Inventory
FH Flyer marking head
Table 1-1 Shipping kit contents
Shipping Box Contents Qty
SYNRAD FH Flyer Marking Head .......................1
FH Flyer Operator’s Manual ................................1
DC Power Cable ......................................................1
Laser Control Cable ................................................1
DB-25 User Interface Connector .......................1
USB Communication Cable ................................1
Spare Power Connector w/ Pins ........................1
Final Test Report (not shown) ............................1
Contents description
A description of each item listed in Table 1-1 follows:
SYNRAD FH Flyer marking head – marks a variety of products and materials in Index or Tracking mode.
FH Flyer Operator’s Manual – provides setup, operation, and maintenance information.
DC Power Cable – connects power from your 30 VDC power supply to the Flyer marking head.
Laser Control Cable – send PWM Command signals generated by Flyer to the laser.
DB-25 User Interface Connector – allows you to connect I/O eld wiring directly to the Flyer head.
USB Communication Cable – completes the USB communications path between your computer and the
Flyer head.
Spare Power Connector w/ Crimp Pins – allows you to fabricate a custom length DC Power cable.
Final Test Report (not shown) – contains data collected during the FH Flyer head’s nal pre-shipment tests
including the actual measured working distance of the focusing lens.
