Inventory
*FLMK mounting kit
Table 1-2 Mounting kit contents
Mounting Kit Contents Qty
Mounting Rail ..........................................................1
L-Bracket ....................................................................1
Beam Enclosure Tube ............................................1
Mounting Bolt Package ........................................1
Contents description
A description of each item listed in Table 1-2 follows:
Mounting Rail – serves as a mounting base for the FH Flyer head, L-bracket, and your SYNRAD laser.
L-bracket – serves as a mount for the Flyer head. When used in conjunction with the appropriate Mounting
Rail and laser, the L-bracket maintains the precise alignment required between the head and laser.
Beam Enclosure Tube – encloses the beam path between the laser’s output and the marking head’s input
aperture.
Mounting Bolt Package – contains seven 1/4–20 × 3/4" socket head capscrews for fastening the L-bracket
and Flyer head to the Mounting Rail.
*Laser
SYNRAD sealed CO
2
lasers are available in powers ranging from 10–125 watts for marking head applica-
tions. Models appropriate for marking applications include 48 Series 10, 25 and 50 W lasers; Evolution
™
Series 100 and 125 W lasers; and the new Firestar
®
Series 30, 40, 60, 70, 80, and 100 W lasers.
Evolution 100/125 W and Firestar t-Series laser shipments include a second box containing the external
RF power supply and associated laser accessories.
* when ordered
