T-Drill S-80 - Page 36

INSTRUCTION MANUAL
36


1 Tool number Idencaon number of the tool
2 Tool status N/A
3 Tool size
Nominal tool size, stamped
on the tool
4
Tool rotaon
angle
5
Tool rotaon
angle S1
6
Tool rotaon
angle S2
7
Collaring tool
diameter
Pin maximum diameter,
with pins fully out.
Measure!
