T-Drill S-80 - Page 39

COLLARING MACHINE
39
S-80
10
Drilling tool
number of teeth
Number of cung edges on
the drill.
11
Collaring tool
diameter
Diameter with pins fully
out. Measure!
12
Collaring tool
shoulder length
Length of tool from boom
to shoulder surface of the
tool = the length of the tool
that will go inside the tube.
13
Collaring tool pin
length
Length of tool from cone
boom to pin ends with
pins fully out
14
Collaring tool
number of pins
A counng parameter for
the program.
15
Trimming tool
diameter
The midst diameter of
the cuer insert path (see
picture)
16
Trimming tool
length
Length of tool from cone
boom to trimming cung
insert / tooth.
17
Trimming tool
cuer width
Width of the cung insert /
cuer blade of the tool.
18
Trimming tool
number of teeth
The trimming tool can be
equipped with more than
1 tooth / cung insert.
Counng parameter.

