T-Drill S-80 - Page 38

INSTRUCTION MANUAL
38

TULEE UUSI KUVA KUN SAAN OHJELMAN
1 Tool number Idencaon number of the tool
2 Tool Status N/A
3 Tool size Nominal tool size, stamped on the tool
4
Tool rotaon
angle
5
Tool rotaon
angle S1
6
Tool rotaon
angle S2
7
Drilling tool
diameter
8
Drilling tool
length
Length of tool from cone
boom to the drill end
9
Drilling tool
cuer length
Length from the cuer
insert to the drill end.
