GTS Technical Manual
26. March 2013 Edition: V2.00/2013 6-6
Copyright © 2013, Diversey Inc.
06.14.30 dashboard - connections - 350B_V1.00.fm
Pos. Plug Description [plug] Pin Description [pin]
1 Main power 1 Main power LED (+3.3VDC)
2 Dosing 2 Adjusting button (+)
3 Dosing ON/OFF 3 ON/OFF button
4 Dosing ON/OFF 4 ON/OFF LED (green)
5 Dosing 5 Level 3 LED (green)
6 Dosing 6 Level 2 LED (green)
7 Dosing 7 Level 1 LED (green)
8 Vacuum ON/OFF 8 ON/OFF button
9 Vacuum ON/OFF 9 ON/OFF LED (green)
10 Status battery 10 Level 2 LED (green)
11 Status battery ** 11 Level 1 LED (green) **
12 Status battery ** 12 Level 1 LED (red) **
13 Service 13 Service LED (red)
14 Machine ON/OFF 14 Machine ON/OFF (+24VDC)
15 Machine ON/OFF 15 Machine ON/OFF button
16 Machine Status 16 Machine ON/OFF LED (green)
17 Charger status 17 Charging LED (Yellow)
18 Charger status 18 Charged LED (green)
19 Charger status 19 Charge failed LED (red)
Table 1: Dashboard connector description
