Remove the screw [55] and the nut

[56]. (TOOL: 2x17mm open end

wrench).

157

Remove the screw [57]. (TOOL: 6mm

hexagon key wrench)

TECHNOGYM ELLIPTICAL Technical Service Guide

Rev. 1.1

- 110 -
