It’s now possible to remove the belt

assembly.

Loosen the nut [72]. (TOOL: 17mm

open end wrench)

TECHNOGYM ELLIPTICAL Technical Service Guide

Rev. 1.1

- 111 -

Uncontrolled copy if printed
