93
Remove the screw [93]. (TOOL: key
wrench for Torx T25 head screw).
Repeat the same procedure also on
the left side.
94
Remove the casing [94] on the right
side.
Repeat the same procedure also on
the left side.
95
Remove the circlip [95]. (TOOL: cir-
clip pliers)
CAUTION: To perform the
procedure wear safety glasses.
TECHNOGYM ELLIPTICAL Technical Service Guide
Rev. 1.1
- 121 -
Uncontrolled copy if printed
