92
Keep the unlocking lever [92] pressed
as shown in gure and raise up the
rear foot assembly.
93
Remove the screw [93]. (TOOL: key
wrench for Torx T25 head screw).
Repeat the same procedure also on
the left side.
94
Remove the casing [94] on the right
side.
Repeat the same procedure also on
the left side.
TECHNOGYM ELLIPTICAL Technical Service Guide
Rev. 1.1
- 127 -
