PURESTRENGTH & BENCHES: Guida all'Assistenza Tecnica - rev. 4.1
Page 5.45
5.13.2. DISASSEMBLING THE EASY-START LEVER GROUP
Figure 5.13-10
1. Position the selector and the carriage
completely down.
Figure 5.13-11
2. Unscrew the screw (a) using a 4mm hexagonal key.
3. Remove the pin (b) from the left side and the spacers.
Figure 5.13-12
4. Unscrew the 2 grub screws (c) using a 4mm
hexagonal key
5. Lower the lever until it touches the ground.
Continued on following page
→
