8.2.3 DISASSEMBLING THE GAS SPRING
1. Move the seat into position
1 (all the way forward) as
shown in the gure, so that
the gas spring is as fully ex-
tended as possible.
1a
2. Unscrew the screw [1a].
(TOOL: 13 mm open end
wrench). It’s now possible
remove the nut.
.
SELECTION 700 Technical Service Guide
Rev. 2.0
- 129 -Document uncontrolled when printed
