8.2.7 DISASSEMBLING THE UPPER FRONT WHEELS
1. Perform the steps described in the paragraph “7.2.6 Disassembling the seat and the back-
rest assembly”
7
2. Remove the snap ring [7].
(TOOL: Circlip pliers).
Repeat the procedure on the op-
posite side.
7a
3. Unscrew the screw [7a].
(TOOL: 6 mm hexagon key
wrench).
Repeat the procedure to remove
the same screw on the opposite
side.
