7.2.5 DISASSEMBLING THE CABLE
7.2.5.1 DISASSEMBLING THE CABLE AT THE WEIGHT STACK SIDE
1. Perform all the necessary steps described in the paragraph “6.2.2 Disassembling the
guards” to remove only the rear protective weight stack panel and access the cable.
For greater clarity, the front protective weight stack panel has also been removed in the
following gures.
8c
8d
2. Unscrew the coun-
ternut [8c].(TOOL:
2x22 mm open
end wrench).
Then remove the
adjuster [8d] turn-
ing with a hand.
