Detailed view of the
loosened bars.
The weight plates under the top one can be now removed/replaced. If it is also necessary to
remove the top plate or replace the top plate bearings, rst perform all the steps described
in the paragraph “6.2.5 Disassembling the cable”. Then remove the top plate [9] as shown
in the gure below.
9
