11. Fasten the ring nut [15b] by turning it round with an hand until it is tight to the puller.
15f
12. Pull out the pin until you
see the insert [15f] shown
in the gure. (TOOL: pull-
er ).
13. Remove the right lever
pulling it upwards.
7.2.13 DISASSEMBLING THE LEVER GROUP
1. Perform all the necessary steps described in the paragraph “6.2.12 Disassembling the right
lever”
SELECTION 700 Technical Service Guide
Rev. 2.0
- 118 - Document uncontrolled when printed
