Technogym SELECTION 700 - Disassembling the Seat Sliding Group

2. It’s now possible to remove the seat padding.
9.2.8 DISASSEMBLING THE SEAT SLIDING GROUP
1. Move the seat into position
9 so that the gas spring is
as fully extended as possi-
ble.
2. Position the pin as shown in
the gure to fasten the seat
sliding group to the ma-
chine frame.
SELECTION 700 Technical Service Guide
Rev. 2.0
- 179 -Document uncontrolled when printed
