Technogym SELECTION 700 - Disassembling the Counterweight

15c
4. Remove the bushing [15c].
(TOOL: 24 mm open end
wrench).
8.2.18 DISASSEMBLING THE COUNTERWEIGHT
1. Perform the necessary steps described in the paragraph “7.2.17 Disassembling the unlock-
ing lever”
15d
2. Remove the screw [15d].
(TOOL: 8 mm hexagon key
wrench).
SELECTION 700 Technical Service Guide
Rev. 2.0
- 151 -Document uncontrolled when printed
