8.2.4
DISASSEMBLING
THE
ECCENTRIC
AND THE
LOWER
WHEEL
ON THE
LEFT SIDE
3
1.
Remove the cap [3] on the
left side of the machine.
(TOOL: Flat screwdriver).
SELECTION 700 T
echnical Service Guide
Rev
. 2.0
- 131 -
Document uncontrolled when printed
128
130
