Technogym SELECTION 700 - Disassembling the Plate under the Seat

9d
7. Press against the two
bushings [9d]. (TOOL: at
screwdriver).
10
8. It’s now possible to remove
the lever for seat unlocking
[10].
8.2.11 DISASSEMBLING THE PLATE UNDER THE SEAT
1. Perform the steps described in the paragraph “7.2.6 Disassembling the seat and the back-
rest assembly”
SELECTION 700 Technical Service Guide
Rev. 2.0
- 139 -Document uncontrolled when printed
