8.2.8 DISASSEMBLING THE UPPER REAR WHEELS
1. To disassemble the upper rear wheels (see the red rectangle in the gure below), perform
the steps 1 and 3 described in the paragraphs “7.2.3 Disassembling the gas spring”and all
the steps described in “7.2.4 Disassembling the eccentric and the lower wheel on the left
side.” and “7.2.5 Disassembling the eccentric and the lower wheel on the right side.”
8.2.9 DISASSEMBLING THE SEAT PADDING
8
1. To disassemble the seat
padding just remove the
four screws (two screws on
each side) under the seat.
(TOOL: 6 mm hexagonal
key wrench).
