10. PROCEDURES FOR DISASSEMBLY-
REASSEMBLY AND REPLACEMENT OF
COMPONENTS- MNAC(LEG PRESS)
10.1 NECESSARY TOOLS
The tools required to carry out all the disassembling, adjustment and maintenance opera-
tions on the equipment are given in the TG SERVICE TOOLS BOX LIST, available on TG
DIRECT and during the training course on the e-learning platform.
Medium-sized Phillips screwdriver;
Hexagon key wrench (4 mm- 5 mm);
Ratchet with hexagonal socket (13 mm);
Ratchet with socket (17 mm);
Ratchet with hexagonal bit (4 mm);
Open end wrench (13 mm)
SELECTION 700 Technical Service Guide
Rev. 2.0
- 187 -Document uncontrolled when printed
