Technogym SELECTION 700 - Disassembling the Plain Bearing

8.2.16 DISASSEMBLING THE PLAIN BEARING
14
1. Remove the plug [14].
(TOOL: Flat screwdriver).
14a
2. Remove the ring nut [14a].
(TOOL: socket wrench for
ring nuts- M25).
During the reassembly
procedure, do not over-
tighten the ring nut. The
roller must be able to
move.
SELECTION 700 Technical Service Guide
Rev. 2.0
- 147 -Document uncontrolled when printed
