13f
8. It’s now possible to remove
the calf-rest or tibia-rest
padding [13f] as shown in
the gure.
During the reassembly of
the roller into the lever as-
sembly, insert the dowel
pin (highlighted in red) into
the hollow that is marked
with the blue arrow.
SELECTION 700 Technical Service Guide
Rev. 2.0
- 146 - Document uncontrolled when printed
