12. ALIGNMENT AND ADJUSTMENTS
12.1 ADJUSTING THE CABLE TENSION
CAUTION: Check the state of deformation of cables: if the cable undergoes a length-
ening, replace it.
In detail, you must execute the following check:
▪ Execute an exercise;
▪ If the cable is loose and then the weight stack doesn’t lift up according to your movement,
regulate the tension of the cable (WARNING: YOU MUST NOT CUT THE CABLE), acting
as detailded in “11.1.1 Adjusting the tension of the cable with crimped tting.” or in “11.1.2
Adjusting the tension of the cable with doubling pulley.”
▪ Machine with adjusting screw: If the adjusting screw must be lowered of more than 2 cm,
replace the cable.
▪ Machine with adjusting pulley: If the cable remains loose, replace the cable.
12.1.1 ADJUSTING THE TENSION OF THE CABLE WITH
CRIMPED FITTING
This operation applies to MNBC- ABDOMINAL CRUNCH, MNCC- LOWER BACK, MNIC-
LEG CURL, MNJC- LEG EXTENSION, MNLC- LAT MACHINE, MNMC- LEG EXTENSION/
CURL, MNOC- ABDUCTOR/ADDUCTOR.
If the weight stack cable is not taut, the problem is due to lengthening of the cable. Therefore, to
solve the problem you must use the cable tension adjustment system. For details see the adjust-
ment procedure detailed here below.
