9a
3.
Remove the pin
[9a]
with
the snap ring.
(TOOL:
at
screwdriver).
9b
4.
It’s now possible to remove
the tie rod with the pin [9b].
SELECTION 700 T
echnical Service Guide
Rev
. 2.0
- 184 -
Document uncontrolled when printed
