2. Position the new pin in
the last plate.
This position is im-
portant to install
the pin with the
correct length
3. Pass the cable through
the hole of the selector
set.
4. Take the bushing [1]
and position it imme-
diately over the rst
plate.
If a portion of old cable
still present, remove it.
5. Pass the new cable
through the bushing
hole (from up to down).
SELECTION 700 Technical Service Guide
Rev. 2.0
- 85 -Document uncontrolled when printed
