Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 7.9
To reassemble the antenna cables (X) and (Y), follow the routing shown below.
The Dissipater (Z) is only on the ATSC and ISDB-T version.
Figure 7.2-8
