Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 8.1
8. ADJUSTMENTS
8.1. BELT TENSION
Figure 8.1-1
Carry out the operations described in paragraph
7.7. “Disassembling the guards
the front guard.
1. Back off the screws (a) and adjust the tension
of the belt by acting on the screw (b).
CAUTION: T
he correct belt tension is
190Hz±10.
CAUTION: If a new belt is used, after
having tensioned it according the above
procedure, it is recommended to exercise
for a minute , in order to “pull” the belt.
Then check again the tension value.
2. At the end of the
tensioning procedure,
remember to lock the screws (a) again.
