Technogym WAVE EXCITE+ - HR Receiver (Chest Belt) Disassembly

Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 7.24
7.4.2. HR RECEIVER (CHEST BELT)
Figure 7.4-6
Carry out the procedure described in paragraph:
7.4.1. “
HR/HS Receiver (Chest Belt / Hand
Sensor)” up to step (4).
1. Unplug the connector cable (a)
from the
receiver.
Figure 7.4-7
CAUTION: During reassembly, position
the receiver so that the coil is facing up
toward the guard (f) as shown in Figure
7.4-3.
To reassemble the HR Receiver, carry out the
above steps in reverse order.
