Technogym WAVE EXCITE+ - Display Fails to Illuminate (Visio Models)

Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 6.12
6.3.3. VISIO MODELS
A
Does the wal l outl et supply the
cor rect voltag e?
Is the power supply cable
OK?
Are the LED on the
CPU Board lit on?
Plug the machi ne into
a wor king
electrical outl et
Repl ace thecable
THE DISPLAY DOES
NOT ILLUMINATE
NO
YES
NO
YES
YES
NO
B
1
Are the fuses OK?
Repl ace the fuses
YES
NO
Continued on following page....
