6.13. THE MACHINE DOES NOT READ THE TGS
The machine displays this error if the TGS reader is not working properly, or if it is not supplied by
the CPU/ARM Board.
THE MACHINE DOES
NOT READ THE TGS
Is the voltag e at the input to the
TGS r eader cor rect?
Is the voltag e at the output to
the Di spl ay Board cor rect?
Repl ace cable
CBQ- 32 and/or CU132
1
2
YES
NO
YES
Repl ace the
Di spl ay Board
NO
A
Is the serial communicati on li nk
between the Di spl ay Board and
the TGS r eader OK?
Repl ace the TGS r eader. Is the
communication li nk between the
Di spl ay Board and the TGS
reader OK?
TGS r eader defecti ve
3
3
YES
NO
YES
Repl ace the
Di spl ay Board
NO
A
Repl ace the Dual TGS
reader
